EMI Systems has access to making customised bullet-proof cars and vans according to specifications, bullion vans for the movement of very important documents, as cash and as a guard against armed robbery.
EMI System realizes that people are vulnerable to attacks even when they are in their cars. The attackers also realize this. It is for this reason that we put the utmost care into every bullet proof car and bullet proof vehicle we customize.
Using the latest space age material available, this vehicles are completely disassembled, install armor components, beef up suspension and reassemble the vehicle so that it looks and handles like it did before armoring.
SPECIFICATION FOR VEHICLES ON STOCK!
PROTECTION LEVEL VR6, according to guidelines BRV 1999
Rifles Projectile Mass Test distance Velocity Energy
Calibre: 7,62 x 51 9,5 g +/- 0,1 g 10 m +/- 0,5 m 830 m/s +/- 10 m/s 3300 J
FJ/PB/SC
Calibre: 5,56 x 45 14,0 g +/- 0,1 g 10 m +/- 0,5 m 950 m/s +/- 10m/s 1800 J
FJ/PB/SCP
Calibre: 7,62 x 39 7,95 g +/- 0,1 g 10 m +/- 0,5 m 710 m/s +/- 10m/s 2090 J
FJ/CB/SC
Calibre: .44 Magnum 15,6 g +/- 0,1 g 5 m +/- 0,5 m 490 m/s +/- 10m/s 1510 J
MRAP Mine-Resistant Ambush Protected 4X4 Vehicle
 |
A 4X4 all-terrain armored vehicle, carrying up to 13 people with high protection level and up to 2.5 Ton payload. Mainly used as a personnel carrier for Tactical command & patrol, Logistic Missions and more.
|
| |
|
| |
|
AMIR MRAP 4 X 4
 |
Designation: AMIR Mine-Resistant Ambush Protected (MRAP) 4X4 Vehicle
Automotive Specifications
Engine: Cummins ISBe 296 Hp 6I.
4X4 Transmission: Alison 2500 SP,
6 Forward and 1 Backwards.
Property |
AMIR MRAP 4X4 |
Unit |
Length |
5,658 |
mm |
Width |
2,400 |
mm |
Height |
2,500 |
mm |
Max permissible weight (GVW) |
15,000 |
Kg |
Curb Weight |
11,400 @ B7 Protection |
Kg |
Max Payload |
3,600 @ B7 Protection |
Kg |
Approach angle |
43 |
deg |
Departure angle |
45 |
deg |
Ramp angle |
137 |
deg |
Front overhang |
1,039 |
mm |
Rear overhang |
1,245 |
mm |
Fording |
Up to 1.0 |
M |
Vertical obstacle |
Up to 55 |
cm |
Trench |
Up to 80 |
cm |
Max Cruising Speed |
110 |
Km/h |
Gradient |
60 |
% |
Side slope |
35 |
% |
Operating temperature |
-26 to +55 |
Celsius |
CTIS |
Ready |
|
Turning diameter |
> = 16.5 |
m |
Ground clearance (under the lower part of the axle) |
340 |
mm |
Acceleration 0 ÷ 50 Km/hour |
12 |
Sec |
Acceleration 0 ÷ 80 Km/hour |
28 |
Sec |
Ditch |
65 |
cm |
Vertical obstacle |
40 |
cm |
Ballistics (standard) |
Mine protection @ wheels and belly |
8 Kg of TNT |
Front wall |
12.7 mm ammunition |
Side walls, rear wall, roof |
B 7 |
|
 |
AMIR General Dimensions |
Side view 4X4 with 365/80 R 20 tires |
| |
|
